BI SQL # 257 : SQL Server DBA Scripts : SQL Agent Job Script

Hi Folks,

In this article we are going to cover SQL Agent Job Script.

In this post we are going to discuss following points:

  • Problem Statement of SQL Script:
  • Description of SQL Script:
  • SQL Script Output Column
  • SQL Script Code
  • SQL Script Output Screenshot
  • User Level to execute

    Problem Statement of SQL Script:

    How to Find SQL Agent Job details?

    Description of SQL Script:

    This script will Find SQL Agent Job details. The script itself explores SQL Agent Job metadata to get job statuses — when the job last ran, when it will run again, an aggregate count of the number of successful and failed executions in the queried time period, T-SQL code to disable the job,etc.

    SQL Script Output Column


    SQL Script Code

    DECLARE @jobHistory TABLE (
        job_id UNIQUEIDENTIFIER
        ,success INT
        ,cancel INT
        ,fail INT
        ,retry INT
        ,last_execution_id INT
        ,last_duration CHAR(8)
        ,last_execution_start DATETIME
        );

    WITH lastExecution
    AS (
        SELECT job_id
            ,MAX(instance_id) AS last_instance_id
        FROM msdb.dbo.sysjobhistory
        WHERE step_id = 0
        GROUP BY job_id
        )
    INSERT INTO @jobHistory
    SELECT sjh.job_id
        ,SUM(CASE
                WHEN sjh.run_status = 1
                    AND step_id = 0
                    THEN 1
                ELSE 0
                END) AS success
        ,SUM(CASE
                WHEN sjh.run_status = 3
                    AND step_id = 0
                    THEN 1
                ELSE 0
                END) AS cancel
        ,SUM(CASE
                WHEN sjh.run_status = 0
                    AND step_id = 0
                    THEN 1
                ELSE 0
                END) AS fail
        ,SUM(CASE
                WHEN sjh.run_status = 2
                    THEN 1
                ELSE 0
                END) AS retry
        ,MAX(CASE
                WHEN sjh.step_id = 0
                    THEN instance_id
                ELSE NULL
                END) last_execution_id
        ,SUBSTRING(CAST(MAX(CASE
                        WHEN le.job_id IS NOT NULL
                            THEN sjh.run_duration
                        ELSE NULL
                        END) + 1000000 AS VARCHAR(7)), 2, 2) + ':' +
        SUBSTRING(CAST(MAX(CASE
                        WHEN le.job_id IS NOT NULL
                            THEN sjh.run_duration
                        ELSE NULL
                        END) + 1000000 AS VARCHAR(7)), 4, 2) + ':' +
        SUBSTRING(CAST(MAX(CASE
                        WHEN le.job_id IS NOT NULL
                            THEN sjh.run_duration
                        ELSE NULL
                        END) + 1000000 AS VARCHAR(7)), 6, 2) AS
        last_duration
        ,MAX(CASE
                WHEN le.last_instance_id IS NOT NULL
                    THEN CONVERT(DATETIME, RTRIM(run_date)) + (
                            (run_time / 10000 * 3600
                                ) + (
                                (run_time % 10000
                                    ) / 100 * 60
                                ) + (run_time % 10000
                                ) % 100
                            ) / (86399.9964
                            )
                ELSE '1900-01-01'
                END) AS last_execution_start
    FROM msdb.dbo.sysjobhistory AS sjh
    LEFT JOIN lastExecution AS le ON sjh.job_id = le.job_id
        AND sjh.instance_id = le.last_instance_id
    GROUP BY sjh.job_id;

    /* We need to parse the schedule into something we can understand */
    DECLARE @weekDay TABLE (
        mask INT
        ,maskValue VARCHAR(32)
        );

    INSERT INTO @weekDay
    SELECT 1
        ,'Sunday'

    UNION ALL

    SELECT 2
        ,'Monday'

    UNION ALL

    SELECT 4
        ,'Tuesday'

    UNION ALL

    SELECT 8
        ,'Wednesday'

    UNION ALL

    SELECT 16
        ,'Thursday'

    UNION ALL

    SELECT 32
        ,'Friday'

    UNION ALL

    SELECT 64
        ,'Saturday';

    /* Now let's get our schedule information */
    WITH myCTE
    AS (
        SELECT sched.NAME AS 'scheduleName'
            ,sched.schedule_id
            ,jobsched.job_id
            ,CASE
                WHEN sched.freq_type = 1
                    THEN 'Once'
                WHEN sched.freq_type = 4
                    AND sched.freq_interval = 1
                    THEN 'Daily'
                WHEN sched.freq_type = 4
                    THEN 'Every ' + CAST(sched.freq_interval AS
                            VARCHAR(5)) + ' days'
                WHEN sched.freq_type = 8
                    THEN REPLACE(REPLACE(REPLACE((
                                        SELECT maskValue
                                        FROM @weekDay AS x
                                        WHERE sched.freq_interval
                                            & x.mask <> 0
                                        ORDER BY mask
                                        FOR XML RAW
                                        ), '"/><row maskValue="',
                                    ', '), '<row maskValue="', '')
                            , '"/>', '') + CASE
                            WHEN sched.freq_recurrence_factor <> 0
                                AND sched.freq_recurrence_factor =
                                1
                                THEN '; weekly'
                            WHEN sched.freq_recurrence_factor <> 0
                                THEN '; every ' + CAST(sched.
                                        freq_recurrence_factor AS
                                        VARCHAR(10)) + ' weeks'
                            END
                WHEN sched.freq_type = 16
                    THEN 'On day ' + CAST(sched.freq_interval AS
                            VARCHAR(10)) + ' of every ' + CAST(sched
                            .freq_recurrence_factor AS VARCHAR(10)
                        ) + ' months'
                WHEN sched.freq_type = 32
                    THEN CASE
                            WHEN sched.freq_relative_interval = 1
                                THEN 'First'
                            WHEN sched.freq_relative_interval = 2
                                THEN 'Second'
                            WHEN sched.freq_relative_interval = 4
                                THEN 'Third'
                            WHEN sched.freq_relative_interval = 8
                                THEN 'Fourth'
                            WHEN sched.freq_relative_interval = 16
                                THEN 'Last'
                            END + CASE
                            WHEN sched.freq_interval = 1
                                THEN ' Sunday'
                            WHEN sched.freq_interval = 2
                                THEN ' Monday'
                            WHEN sched.freq_interval = 3
                                THEN ' Tuesday'
                            WHEN sched.freq_interval = 4
                                THEN ' Wednesday'
                            WHEN sched.freq_interval = 5
                                THEN ' Thursday'
                            WHEN sched.freq_interval = 6
                                THEN ' Friday'
                            WHEN sched.freq_interval = 7
                                THEN ' Saturday'
                            WHEN sched.freq_interval = 8
                                THEN ' Day'
                            WHEN sched.freq_interval = 9
                                THEN ' Weekday'
                            WHEN sched.freq_interval = 10
                                THEN ' Weekend'
                            END + CASE
                            WHEN sched.freq_recurrence_factor <> 0
                                AND sched.freq_recurrence_factor =
                                1
                                THEN '; monthly'
                            WHEN sched.freq_recurrence_factor <> 0
                                THEN '; every ' + CAST(sched.
                                        freq_recurrence_factor AS
                                        VARCHAR(10)) + ' months'
                            END
                WHEN sched.freq_type = 64
                    THEN 'StartUp'
                WHEN sched.freq_type = 128
                    THEN 'Idle'
                END AS 'frequency'
            ,ISNULL('Every ' + CAST(sched.freq_subday_interval AS
                    VARCHAR(10)) + CASE
                    WHEN sched.freq_subday_type = 2
                        THEN ' seconds'
                    WHEN sched.freq_subday_type = 4
                        THEN ' minutes'
                    WHEN sched.freq_subday_type = 8
                        THEN ' hours'
                    END, 'Once') AS 'subFrequency'
            ,REPLICATE('0', 6 - LEN(sched.active_start_time)) + CAST(
                sched.active_start_time AS VARCHAR(6)) AS
            'startTime'
            ,REPLICATE('0', 6 - LEN(sched.active_end_time)) + CAST(
                sched.active_end_time AS VARCHAR(6)) AS 'endTime'
            ,REPLICATE('0', 6 - LEN(jobsched.next_run_time)) + CAST(
                jobsched.next_run_time AS VARCHAR(6)) AS
            'nextRunTime'
            ,CAST(jobsched.next_run_date AS CHAR(8)) AS
            'nextRunDate'
        FROM msdb.dbo.sysschedules AS sched
        JOIN msdb.dbo.sysjobschedules AS jobsched ON sched.
            schedule_id = jobsched.schedule_id
        WHERE sched.enabled = 1
        )
    /* Finally, let's look at our actual jobs and tie it all together */
    SELECT CONVERT(NVARCHAR(128), SERVERPROPERTY('Servername')) AS
        [serverName]
        ,job.job_id AS [jobID]
        ,job.NAME AS [jobName]
        ,CASE
            WHEN job.enabled = 1
                THEN 'Enabled'
            ELSE 'Disabled'
            END AS [jobStatus]
        ,COALESCE(sched.scheduleName, '(unscheduled)') AS
        [scheduleName]
        ,COALESCE(sched.frequency, '') AS [frequency]
        ,COALESCE(sched.subFrequency, '') AS [subFrequency]
        ,COALESCE(SUBSTRING(sched.startTime, 1, 2) + ':' + SUBSTRING(
                sched.startTime, 3, 2) + ' - ' + SUBSTRING(sched.
                endTime, 1, 2) + ':' + SUBSTRING(sched.endTime, 3, 2), ''
        ) AS [scheduleTime] -- HH:MM
        ,COALESCE(SUBSTRING(sched.nextRunDate, 1, 4) + '/' + SUBSTRING
            (sched.nextRunDate, 5, 2) + '/' + SUBSTRING(sched.
                nextRunDate, 7, 2) + ' ' + SUBSTRING(sched.nextRunTime
                , 1, 2) + ':' + SUBSTRING(sched.nextRunTime, 3, 2), '') AS
        [nextRunDate]
        ,COALESCE(jh.success, 0) AS [success]
        ,COALESCE(jh.cancel, 0) AS [cancel]
        ,COALESCE(jh.fail, 0) AS [fail]
        ,COALESCE(jh.retry, 0) AS [retry]
        ,COALESCE(jh.last_execution_id, 0) AS [lastExecutionID]
        ,jh.last_execution_start AS [lastExecutionStart]
        ,COALESCE(jh.last_duration, '00:00:01') AS [lastDuration]
        ,'EXECUTE msdb.dbo.sp_update_job @job_id = ''' + CAST(job.
            job_id AS CHAR(36)) + ''', @enabled = 0;' AS
        [disableSQLScript]
    FROM msdb.dbo.sysjobs AS job
    LEFT JOIN myCTE AS sched ON job.job_id = sched.job_id
    LEFT JOIN @jobHistory AS jh ON job.job_id = jh.job_id
    WHERE job.enabled = 1 -- do not display disabled jobs
        ORDER BY nextRunDate;

    SQL Script Output Screenshot


    User Level to execute

    300

    Hope you will like the SQL Agent Job Script.
